Semi Electric Portable Stacker 1Ton 0.5Ton 3m Lift Height EPS Forklift

Basic Information

Place of Origin:	China
Brand Name:	KAD
Certification:	CE/ISO9001
Model Number:	CDD05C

Minimum Order Quantity:	1
Price:	$1000
Packaging Details:	iron pallet +plastic film
Delivery Time:	7work days
Payment Terms:	L/C, D/A, D/P, T/T, Western Union
Supply Ability:	50units/month

Get Best Price Contact Now

Model NO.:	CDD05C	Load Capacity:	1t
Load Center:	500mm	Lift Height:	1600mm
Battery Capacity:	24V/210ah	Fork Size:	122010040mm
Ground Clearance:	30mm	Turning Radius:	1500mm
Driving Speed:	4km/h	Gradient:	3°/5°
Driving Motor:	0.8KW	Lifting Motor:	0.8KW
Tyre Size:	300/250mm	Overall Size:	1570786/9361150mm
Weight:	215kg

Semi Electric Portable Stacker 1Ton 0.5Ton 3m Lift Height EPS Forklift

The wide-view mast and smooth vehicle shape, with multi-curved cover parts, unrestricted vision and improved working efficiency; the H-channel steel mast is resistant to bending and torsion, strong and durable, ensuring the vehicle's load capacity; the maintenance-free AC motor minimizes maintenance costs; the standard integrated handle integrates multiple functions for quick and easy operation; the front cover is easy to disassemble and various components are centrally arranged to make maintenance faster and smoother.
advantage:

1. All-Alloy-Steel Construction (High Strength & Rigidity)
2. Hydraulic Operation (Enhanced Reliability & Durability) 3.Lightweight Design (Improved Maneuverability)
4.High-Efficiency Gear Pump & Motor (Energy-Saving)
5.Independent Power & Gravity Modes (Gravity Mode for Zero-Power Descent & Extended Range)
6.Chrome-Plated Finish (Excellent Corrosion/Wear Resistance, Maintains Smooth Telescopic Action)

If you have any questions about this Semi-Electric Self-loading Stacker, please feel free to contact me via the following methods. I will be on call 24 hours a day. Thank you.

Model		CDD05C	CDD07Z	CDD10Y
Type of Power		Battery	Battery	Battery
Max. Load	kg	500	700	1000
Load Center	mm	400	400	400
Wheelbase	mm	815	788	780
Wheel Distance: FR	mm	380	405	398/518
Wheel Distance: RR	mm	665/815	690/810	708/928
Type of Operation		Walk	Walk	Walk
Front Wheel	mm	Φ70×60	Φ80×60	Φ70×60
Universal Wheel	mm	Φ100×45	Φ100×50	Φ100×50
Middle Wheel	mm	Φ45×26	Φ65x30	Φ65×30
Length of Outriggers	mm	746	735	780
Max. Fork Height	mm	800/900/1000/1100/1200/1300/1500/1600	800/900/1000/1100/1200 /1300/1500/1600	800/900/1000/1100/1200 /1300/1500/1600
External Distance Between Forks	mm	535/685	565/685	565/(685)
Length of Fork	mm	1150	1150	1150
Thickness of Fork	mm	60	60	60
Width of Fork	mm	155	190	193
Overall Length	mm	1570	1552	1544
Overall Width	mm	786/936	809/929	835/955
Overall Height (Mast Closed)	mm	1150/1207/1307/1407/1507/1607/1807/1907	1155/1255/1355/1455/1555/1655/1855/1955	1166/1266/1366/1466/1566 /1666/1866/1966
Overall Height (Max. Fork Height)	mm	1870/2070/2270/2470/2670/2870/3270/3470	1875/2075/2275/2475/2675/2875/3275/3475	1850/2050/2250/2450/2650 /2850/3250/3450
Lifting speed	mm/s	55	55	55
Descent speed	mm/s	80	100	100
Lift Motor Power	kw	0.8	0.8	1.6
Battery Voltage	v	12	12	12
Battery Voltage	Ah	52	52	52
Battery Weight	kg	13.5	13.5	13.5
Total Weight(Include Battery)	kg	214/218/223/228/233/240/255/260	243/247/251/255/259/263/272/276	285/290/295/300/305 /310/319/324
