5 Ton Heavy Duty Diesel Forklift Imported Engine Unmatched Power

Basic Information

Place of Origin:	China
Brand Name:	KAD
Certification:	CE
Model Number:	CPD

Minimum Order Quantity:	1
Price:	6000-8000
Packaging Details:	iron pallet +plastic film
Delivery Time:	10 work days
Payment Terms:	L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability:	50units/month

Get Best Price Contact Now

Load Capacity:	1000-3500kg	Load Height:	3000mm-6000mm
Battery:	12V/80AH	Type:	Diesel Foklift
Color:	Customer Demanded	Feature:	Easy Operation Safety Convenience
Application:	Industry	Certification:	CE
Power Type:	Diesel Power
Highlight:	5 ton diesel forklift imported engine , heavy duty diesel forklift unmatched power , battery operated forklift with warranty

5 Ton Heavy Duty Diesel Forklift Imported Engine Unmatched Power

This next-generation diesel forklift integrates intelligent technology with human-centric design to maximize productivity, reduce operator fatigue, and provide unparalleled control.

Smart Power Management System: Features an advanced ECU that automatically optimizes fuel injection and engine power output based on the load, significantly boosting fuel economy without sacrificing performance.
Enhanced Operator Ergonomics: The ultra-wide view mast is standard, combined with a fully adjustable suspension seat, a low-effort steering wheel, and logically placed controls to minimize fatigue during long shifts.
Integrated Safety & Lighting Package: Goes beyond LED lights with additional standard features like a rearview camera interface, LED warning beacons, and a digital display providing real-time vehicle status alerts.
Data & Connectivity Ready: Comes pre-equipped with ports for fleet management and telematics systems, allowing for easy monitoring of location, fuel usage, and maintenance needs.

1. Integrated welded frame, sturdy and reliable, reinforced tail stock, enhancing overall vehicle safety.
2.Adopting a wide field of view gantry, the driver's field of view is wider. The gantry, chain, and oil cylinder are designed with high strength, and have strong overload capacity. Various models of height gantry can be selected.
3.Using a dual filter air filter, dual filtration extends engine life.

4. Add shock-absorbing rubber pads at the connection between the steering axle and the frame to reduce vehicle vibration and improve driving comfort.

If you have any questions about this DIESEL FORKLIFT, please feel free to contact me via the following methods. I will be on call 24 hours a day. Thank you.

Model		CPC30/CPCD30
Rated Capacity	kg	3000
Load Center	mm	500
Power Type		Diesel
Max, Lifting Speed (No-Load / Full-Load)	mm/s	450 / 440
Max. Driving Speed (Full-Load /No-Load)	km/h	18 / 20
Max. Towing Capacity(Full-Load/No-Load	kN	15.5 / 10.5
Gradeability(Full-Load/No-Load)	%	15 / 20
Lifting Height	mm	3000
Free Lift Height	mm	80
Mast Tilting Angle (Forward-Backward)	(°)	6 / 12
Min.Turning Radius	mm	2530
Min.Right Angle Aisle Width	mm	2050
Min. Ground Clearance	mm	135
Overall Length (including Fork)	mm	4170
Overall Width	mm	1230
Overall Height (Mast Lowered)	mm	2110
Overall Height (Mast Extended)	mm	4270
Overall Height to Overhead	mm	2105
Front Overhang	mm	465
Wheelbase	mm	1760
Front Tread	mm	1000
Rear Tread	mm	970
Front Wheel	mm	28*9-15
Rear Wheel	mm	6.50-10
Fork Width	mm	122
Fork Thickness	mm	45
Backrest Height	mm	1225
Fork Length	mm	1220
Engine Model		C490BPG
Rate Power	KW	40
Rotate Speed at Rate Power	rpm	2650
Max. Torque	Nm	162
Rotation Speed at Max. Torque	rpm	1800 ~ 1900
Type of Power Shift		Mechanical / Hydraulic
Curb Weight	kg	4100

5 Ton Heavy Duty Diesel Forklift Imported Engine Unmatched Power 3

Q1. What is your terms of packing? A: Generally, we pack our goods in paper package and Iron pallet. We can pack the goods in your branded boxes after getting your authorization letters.

Q2. What is your terms of payment? A: T/T 30% as deposit, and 70% before delivery. We'll show you the photos of the products and packages before you pay the balance. Or As negotiated

Q3. What is your terms of delivery? A: EXW, FOB, CFR, CIF, DDU.

Q4. How about your delivery time? A: Generally, it will take 5 to 30 days after receiving your deposit. The specific delivery time depends on the items and the quantity of your order.

Q5. Do you test all your goods before delivery? A: Yes, we have 100% test before delivery

Q6: How do you make our business long-term and good relationship? 1. We keep good quality and competitive price to ensure our customers benefit ; 2. We respect every customer as our friend and we sincerely do business and make friends with them, no matter where they come from.
