Place of Origin: | Jiangsu, China |
---|---|
Minimum Order Quantity: | 1 |
Price: | $420-580 |
Battery Voltage: | 48V | Battery Capacity: | 40A |
---|---|---|---|
Load Capacity: | 2000kg | Fork Length: | 1150 Mm |
Fork Width: | 150 Mm | Turning Radius: | 2400 Mm |
Wheelbase: | 1335 Mm | Grade Ability Laden: | 0.4 |
Grade Ability Unladen: | 0.4 | Load Centre Distance: | 800 Mm |
Drive Motor Power: | 0.75 Kw | Lift Motor Power: | 0.5 Kw |
Travel Speed Laden: | 4 Km/h | Travel Speed Unladen: | 4.5 Km/h |
Noise Level: | <74 DB(A) | ||
Highlight: | 48V Lithium-Ion Battery Electric Pallet Jack,CE Approved Warehouse Forklift,Affordable Electric Powered Pallet Truck |
Category | Parameter | Symbol | Unit | Value |
---|---|---|---|---|
Identification | Manufacturer | EP | ||
Model designation | F5pro | |||
Drive unit | Electric | |||
Operator type | Pedestrian | |||
Rated capacity | Q | kg | 1500 | |
Dimensions | Load center distance | c | mm | 600 |
Overall length | l1 | mm | 1550 | |
Overall width | b1/b2 | mm | 695/590 | |
Performance | Travel speed (laden/unladen) | km/h | 4/4.5 | |
Max. gradeability (laden/unladen) | % | 5/16 | ||
Electric | Battery voltage/nominal capacity | V/Ah | 24/20 |
