Place of Origin: | China |
---|---|
Brand Name: | KAD |
Certification: | CE |
Model Number: | CDDL |
Minimum Order Quantity: | 1unit |
Price: | $2200/UNIT |
Packaging Details: | iron pallet +plastic film |
Delivery Time: | 7work days |
Payment Terms: | T/T, L/C, D/A, D/P, Western Union, MoneyGram |
Supply Ability: | 50units/month |
Product Name: | Electric Walkie Stacker | Load Capacity: | 1200/1600 |
---|---|---|---|
Lift Height: | 1600/200012500/3000 | Length: | 1770 |
Wdith: | 850 | Battery Capacity: | 2*7012*80 |
Highlight: | Light Weight Electric Stacker Reach,Compact Structure Electric Stacker Reach,Low Price Electric Stacker Reach |
Light Weight And Compact Structure Electric Stacker Reach With Low Price
Product Description
design features support legs extending on either side of the load, making it ideal for handling pallets with gaps between the cargo, enhancing both stability and versatility.
Key features include:
This type of stacker truck is widely used in logistics centers, warehouses, and manufacturing industries, especially suitable for scenarios that require lifting, stacking, or transporting heavy objects.
Model
|
|
CDD1030
|
CDD1530
|
Load Capcity
|
kg
|
1000
|
1500
|
Lifting Height
|
mm
|
1600
|
1600
|
Load Center
|
mm
|
500
|
500
|
Fork Size
|
mm
|
1220*100*40
|
1220*100*40
|
Ground Clearance
|
mm
|
130
|
130
|
Pedal Length
|
mm
|
410
|
410
|
Handler Heihgt
|
mm
|
1490
|
1490
|
Outer Distance Between Forks
|
mm
|
685
|
685
|
Inner Distance Between Forks
|
mm
|
345
|
345
|
Tyre type
|
|
Polyurethane
|
Polyurethane
|
Control Way
|
|
Handler
|
Handler
|
Speed Regulation Way
|
|
Stepless Speed Regulation
|
Stepless Speed Regulation
|
The Min. Turning Radius
|
mm
|
1500
|
1500
|
Driving Speed with Full Loads
|
km/h
|
4
|
4
|
Gradient
|
°
|
10
|
10
|
Battery
|
V/Ah
|
24V/180A
|
24V/180A
|
Driving Motor
|
KW
|
1.2
|
1.2
|
Lifting Motor
|
KW
|
2.2
|
2.2
|
Tyre Size
|
mm
|
300/250
|
300/250
|
Overall Size
|
mm
|
2170*1570*2100
|
2170*1570*2100
|
Weight
|
kg
|
900
|
900
|
Reference Working Time
|
h
|
6
|
6
|
Increased height each tonnage
|
mm
|
1600/2000/2500/3000/3500
|
|
Max height
|
2100/1600/1850/2100/2350
|
Lightweight and flexible: Lightweight stacker trucks are usually lightweight and have a compact body design, making it easy for operators to carry and stack in narrow passages and limited spaces.
Easy to operate: Due to its small size and simple structure, it is easy to operate and suitable for operators of different levels.
Low cost: Compared to fully electric or large stacking equipment, lightweight stacking trucks are usually more affordable and suitable for small businesses or users with limited budgets.
Easy maintenance: Lightweight devices have a relatively simple structure and lower maintenance and repair costs.
Environmental protection and energy conservation: Lightweight stacker trucks are often manual or semi electric, with lower energy consumption and reduced demand for electricity.
Multifunctionality: Suitable for various scenarios, not only can it handle goods, but it can also be used for stacking to meet different storage needs.
