Taizhou Kayond Machinery Co.,Ltd
| Place of Origin: | Jiangsu,China |
|---|---|
| Brand Name: | KAD |
| Certification: | CE |
| Model Number: | CPD20/30/40/50 |
| Minimum Order Quantity: | 1 unit |
| Price: | $8000-$20000/unit |
| Packaging Details: | Iron Pallet |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 1000units/month |
| Condition: | New | Type: | Electric Forklift Truck |
|---|---|---|---|
| Power Souce: | DC Motor | Rated Loading Capacity: | 2000/3000/4000/5000kg |
| Min. Lifting Height: | 85mm | Max. Lifting Height: | 3000mm-6000mm |
| Fork Width: | Adjustable | Fork Length: | 1070mm |
| Overall Dimensions: | 2380x1090x2125mm | Weight: | 2250kg |
| After-sales Service Provided: | Online Support,Video Technical Support | Product Name: | Electric Forklift Truck |
| Color: | Customer Demanded | Warranty: | 1 Year |
| Highlight: | 2500kg sit down Battery forklift,4 Directional Battery Operated Forklift,2500kg compact Battery Forklift |
||
1. Equipped with original imported American Curtis electric control system.
2. High voltage and large capacity battery can supply the forklift with strong power.
3. Equipped with famous brand parts, like Shimadzu pump and valve, Eaton pipe, Nok hydraulic cylinder seals, Toyota seat with safety belt,and so on.
4. Imported brand Accelerator and Power Connector.
5. Dynamic load sensing priority steering system and efficient drive system(Advance H-Type remote drive unit make driving more stable).
6. Fully enclosed instrument panel cover.
7. Battery side-take function.
Electric forklift truck adopts electric drive, compared with the internal combustion forklift truck, it is pollution-free, easy to operate, energy-saving and efficient. With the development of economy and the improvement of environmental protection and energy saving, electric forklift truck develops rapidly. Market sales are increasing year by year. Especially in the port, storage and tobacco, food, textile and other industries, electric forklifts are gradually replacing the internal combustion forklifts.
1. Thickened fork, thickened load bearing, not easy to deformation, thickened baking paint, not easy to fade.
2. Solid rubber tires, suitable for all kinds of ground, wear - resistant and good shock - absorbing effect
3. The console is easy to operate and easy to understand.
4. Side shifter can be installed, the fork can be moved left and right side, more convenient to operate.
5. High strength gate frame channel steel body, no deformation, stable lifting, bearing capacity and set reinforcement between the gate frame.
6. Economical and durable double cylinder door frame with wide field of vision.
|
Model Parameter |
CPD1030 | CPD1530 | CPD2030 | CPD3030 |
| Load Capacity(Kg) | 1000 | 1500 | 2000 | 3000 |
| Lift Height(m) | 3000 | 3000 | 3000 | 3000 |
| Load Center (mm) | 500 | 500 | 500 | 500 |
| Fork Length (mm) | 1070 | 1070 | 1070 | 1070 |
| Lowest height(mm) | 120 | 120 | 120 | 120 |
| Manipulation Way | Steering Wheel | Steering Wheel | Steering Wheel | Steering Wheel |
| Tyres | Solid Wheel | Solid Wheel | Solid Wheel | Solid Wheel |
| Dimension of Driving Wheel | 510mm | 510mm | 560mm | 650mm |
| Speed at Full Load km/h | 15 | 15 | 15 | 15 |
| Lifting Speed at full Load mm/sec | 200 | 200 | 200 | 200 |
| Speed Control Way | Stepless Speed Regulation | Stepless Speed Regulation | Stepless Speed Regulation | Stepless Speed Regulation |
| Door Frame Tilt Angle ° | 3~6 | 3~6 | 3~6 | 3~6 |
| Gradient at full Load ° | 15 | 15 | 15 | 15 |
| Battery V/Ah | 48/240 | 48/270 | 48/270 | 48/420 |
| Working Time(for reference) (h) | 3 | 3 | 3.5 | 6 |
| Driving Motor (kw) | 4 | 4.2 | 5 | 8 |
| Lifting Motor (kw) | 3 | 3 | 5.5 | 5.5 |
| The Min. Turning Inner Radius (mm) | 2000 | 2000 | 2100 | 2150 |
| L X W X H Dimension (mm) | 3380*1050*2100 | 3380*1050*2100 | 3450*1100*2100 | 3600*1160*2120 |
| weight(kg) | 2200 | 2400 | 2800 | 3800 |
| lifting Height at each weight (mm) | 1600/2000/2500/3000/3500 | |||
| Height of Door Frame (mm) | 2080/1600/1850/2080/2350 | |||
