Taizhou Kayond Machinery Co.,Ltd
| Place of Origin: | Jiangsu,China |
|---|---|
| Brand Name: | KAD |
| Certification: | CE |
| Model Number: | HPT30N |
| Minimum Order Quantity: | 6units |
| Price: | $110-$135/unit |
| Packaging Details: | Plywood case |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 100000units/month |
| Fork Width: | 550/685MM | Max. Lifting Height: | 185/195mm |
|---|---|---|---|
| Model: | HPT30N | Condition: | New |
| Lift Drive / Actuation: | Hydraulic Pallet Truck | Rated Loading Capacity: | 3000kg,2000/2500KG |
| Min. Lifting Height: | 85mm | Fork Length: | 1150/1220mm |
| Weight: | 75kg | Color: | Yellow,Red,Blue,customized,All Accepted |
| Certification: | CE | After-sales Service Provided: | Video Technical Support |
| Warranty: | 1 Year | ||
| Highlight: | 185mm hand pallet truck 3000kg,3000kg hand hydraulic pallet truck,185mm hand pallet pump truck |
||
Hand pallet truck is the most convenient, most effective and common loading and unloading tool in pallet transportation tools. It is widely used in logistics, warehouse, factory and so on.
1. Forks are processed with whole press forming technology and coated with powder painting, torsion and fading-resistant.
2. Excellent whole casting hydraulic pump and welded pump for your choice, robust and durable, with fine control of lowering speed and overload valve. Integrated pump is easy to maintain.
3. The wheel material has Nylon, PU, Rubber, Iron to choose from. The guide wheel is optional to ensure easier operation.
4. Ergonomically designed handle with comfortable rubber grip allows the optimized safety.
1.Guide wheels
2.Full reinforcement
3.Customized forks for rollers
|
Item/Model |
Unit |
|
||
|
Capacity |
Kg |
2500 |
3000 |
5000 |
|
Min.fork height |
Mm |
80 |
100 |
|
|
Max fork height |
Mm |
190 |
210 |
|
|
Steering wheel |
Mm |
Nylon/PU |
180*60 |
|
|
Load roller |
Mm |
Nylon/PU |
88*106 |
|
|
Each fork width |
Mm |
150 |
180 |
|
|
Each fork thickness |
Mm |
3 |
4 |
5 |
|
Width |
Mm |
550/685 |
700 |
|
|
Length |
Mm |
1150/1220 |
1310 |
|
|
Weight |
kg |
68 |
75 |
200 |
