Taizhou Kayond Machinery Co.,Ltd
| Place of Origin: | Jiangsu,China |
|---|---|
| Brand Name: | KAD |
| Certification: | CE |
| Model Number: | HPT50 |
| Minimum Order Quantity: | 6units |
| Price: | $280-$350/unit |
| Packaging Details: | Plywood case |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 1000units/month |
| Lift Drive / Actuation: | Hydraulic Pallet Truck | Rated Loading Capacity: | 5000kg |
|---|---|---|---|
| Fork Width: | 550/685MM | Model: | HPT50N |
| Condition: | New | Max. Lifting Height: | 185/195mm |
| Min. Lifting Height: | 85mm | Fork Length: | 1150/1220mm |
| Weight: | 120kg | Color: | Yellow,Red,Blue,customized,All Accepted |
| Certification: | CE | After-sales Service Provided: | Video Technical Support |
| Warranty: | 1 Year | ||
| High Light: | 5000kg warehouse pump truck,5000kg pallet pump truck,HPT50N manual pump truck |
||
■ Modular design for valve „make minimize failure rate
■ Forging rocker arm with 45 carbon steel, greatly improve flex resistance
■ Long time overload is not easy to deformation
■ Pump body overload protection down smoothly use safety
■ Lifting down by handle or foot easy to use
■ Frame design strong capacity is strong
■ Steady lifting falling ,speed can be control■ Modular design for valve „make minimize failure rate
1.Guide wheels
2.Full reinforcement
3.Customized forks for rollers
| Item | HP 5.0T | DF 5.0 | |
| Capacity Q | (kg) | 5000 | 5000 |
| Min.fork height H1 | (mm) | 85 | 85 |
| Max.fork height HI | (mm) | 200 | 200 |
| Steering wheel | (mm) | 180X62 | 180X50 |
| Load roller | (mm) | 78X70 | 80X70 |
| Size of fork Exs | (mm) | 160 | 180 |
| Width overall forks B | (mm) | 540 / 685 | 550/685 |
| Fork Length L | (mm) | 1070 /1220 | 1150 /1220 |
| Net weight | (kg) | 125 | 140 |
